Nova Screen
Pure nickel electroforming, uncompromising precision at every stage. Nova Screen deliver consistent quality across all rotary printing machines and applications.
Nova Screen are electroformed using pure nickel a manufacturing process that demands deep technical knowledge and uncompromising precision at every stage of production. Every screen undergoes rigorous in-process quality control before leaving the facility. Nova Rotary Screens are fully compatible with all rotary screen printing machines, irrespective of whether they operate with metal or rubber squeegee systems.
The Nova Screen range is available across a wide selection of repeat sizes, lengths, and mesh counts, giving textile printers the flexibility to match the right configuration to every production requirement. Nova Screen are characterised by their exceptional dimensional stability, which makes them easier and safer to handle while significantly extending their serviceable life on the machine.
Every Nova Screen is manufactured to be uniform and fault-free, with precise repeat accuracy across the full production run. Their excellent ductility substantially reduces the risk of cracking, particularly under high squeegee tension conditions. The specially developed surface texture of Nova Screen provides strong, reliable adhesion with all widely used coating emulsions. The optimised relationship between aperture size and the surrounding web geometry ensures flawless print results across all dye types and textile substrates.
Nova Screen 80 ED
The 80 ED is an extra-thick, extra-durable mesh screen built for demanding production environments. With a wall thickness of 100 microns and 14% open area, the 80 ED delivers outstanding screen longevity, maintaining print quality and structural integrity even at elevated printing speeds and when working with highly corrosive paste formulations. The result is a screen that lowers the cost per print run while sustaining consistent output quality throughout its extended operational life.
Nova Screen 100 ED
The 100 ED represents a significant step forward within the Nova ED range. With a wall thickness of approximately 105 microns — compared to around 95 microns for a conventional 100 mesh — and an open area of approximately 14% against the standard 8%, the 100 ED delivers a clear technical advantage over conventional alternatives. This combination makes surface, outline, and fine-detail printing down to 0.20mm achievable even at higher operating speeds, with minimum breakage risk throughout the print run.
Beyond the quality printing benefits, the Nova ED screens are also demonstrably more economical in operation. The increased wall thickness translates directly into greater durability and a longer service life compared to standard mesh screens.
| (Mesh) | (um) | (%) | (um) |
|---|---|---|---|
| 135 | 115 | 20 | 92 |
| 135V | 115 | 20 | 92 |
| 165 | 110 | 18 | 71 |
| 165V | 110 | 18 | 71 |
| 195 | 105 | 15 | 60 |
Precision Engineered for Every Print
India and international markets where quality is never a compromise.
